10pcs gPV Solar PV Fuse Link 20A 1000V DC 10x38mm Fuse 33kA Breaking Capacity for Solar, PV Combienr Box (20 Amp)
Product details
| Management number | 247164162 | Release Date | 2026/08/16 | List Price | US$5.60 | Model Number | 247164162 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 【Circuit Protection】Rated voltage DC1000V, rated current 20A. Fuse link can be widely applied in scenarios such as PV combiner boxes and inverters, providing highly reliable DC fuse element protection, short-circuit protection, and overload protection
- 【Fast-Acting High-Breaking Capacity】Features a high-performance fuse element structure with 20A current capacity and 33kA breaking capability. The fuse core rapidly interrupting overloads and short-circuit faults to ensure safe system operation.
- 【Ceramic Housing and Silver Conductor】 The ceramic material offers high-temperature resistance, impact resistance, and excellent insulation properties, ensuring structural integrity under extreme conditions and effectively isolating arcs. The silver fuse element boasts exceptional conductivity for rapid and precise response, enabling swift and stable melting during overcurrent events.
- 【Wide Compatibility & Easy Installation】Compatible with standard 10×38mm fuse holder bases, suitable for residential and commercial PV systems. Simple installation and replacement meet diverse application needs.
- 【Internationally Certified & Reliable】Certified by CE, TUV, RoHS, and ISO. Complies with IEC 60269-6 international standards for PV systems. Advanced arc-quenching technology ensures stable operation under high-voltage conditions, delivering reliable protection performance.
| ASIN | B0FPCHXXMP |
|---|---|
| Model | 20A 10Pcs |
| Voltage | 1000 |
| Brand Name | CNLonQcom |
| Unit Count | 10 Count |
| Part Number | 20A 10Pcs |
| Manufacturer | CNLonQcom |
| Material Type | Ceramic |
| Current Rating | 20 A |
| Item Dimensions | 1.5 x 0.4 x 0.4 inches |
| Maximum Current | 20 A |
| Number of Items | 10 |
| Included Components | 20A fuse link x 10 pcs |
